Tech Maven Geospatial has prepared ready-to-go Foundational GEOINT Data

  • for your offline mapping needs

  • on-premises/within firewall Mapping Environment



  • Raster Tiles (3857)
  • Vector Tiles
  • Vector Features
  • Terrain/Elevation Tiles (multiple formats are available)

in both MBTiles and GeoPackage SQLite Databases formats)

We can also translate these formats into other widely used formats to meet whatever specific need you have and to accommodate your mapping platform. See List

PRICING:

WORLDWIDE $10,000/year for unlimited use and rights + our pre-staged Countries, Regions, US States and Canadian Provinces

USA (CONUS, Alaska and Hawaii and Territories)  – $4,500/year for unlimited use and rights

Canada $4,500/year unlimited use and rights

Worldwide Data

USA

Canada

The Data includes the following:

  • OSM Vector Tiles  (produced regularly from Planet PBF Download from Open Street Map) Compatible with OpenMapTiles/MapTiler Data GL JSON Stylesheets  85gb
  • HillShade Raster Tiles 0-12 400gb
  • Contour Line Vector Tiles with elevation labels  9-14 143gb
  • Stamen Terrain Terrain Background Style – Shaded Relief Map
  • Stamen Terrain derived from OSM -Reference Lines and Reference Labels Raster Tiles (great for combining with Satellite imagery to make hybrid )
  • Thunderforest Outdoors Basemap
  • Satellite Imagery
  • Quantized Mesh Terrain Tiles
  • RGB Encoded PNG Elevation Tiles MapZen Terrarium Spec



Optional Data is rapidly produced for that Area of Interest from Our GeoRequest API

  • GeoNames Points of Interest   GeoPackage Vector Features and Vector Tiles
  • OSM Points of Interest – Geopackage Vector Features and Vector Tiles
  • Many other data products

In addition, we can develop custom offline maps to suit any needs

We have the bandwidth and CPU’s to handle processing satellite imagery to zoom level 24 and large scales

Raster Tiling

Specialized Raster Tiling Services

Image Optimization – Providing the best compromise for file size and quality

Composing multiple tile layers together

Changing Colors, Adjusting Transparency/Opacity

Vector Tiles

MapBox Vector Tiles (GZipped PBF Protocol Buffers) in TMS schema in mbtiles or can be folder of XYZ or TMS tiles.

We have tools to package Vector Tiles inside GPKG

We have specialized tools for building vector tiles from databases and Vector GIS Data.

Elevation/Terrain Tiles

We have optimized terrain tiles for processing in HGT format for the entire world on our server

We have worldwide elevation data from multiple sources

There are several formats we can deliver.

  1. PNG with RGB values with a formula representing height/elevation (Either MapZen or MapBox Spec)
  2. Cesium Terrain Formats – Quantized Mesh and Heightmap Formats
  3. GeoPackage Gridded Coverage Elevation
  4. DTED2 or DTED3 for ATAK/WINTAK and other Mapping Clients

extracts/downloads from Publicly available Tile Servers, Map Servers

Build custom offline maps from your existing GIS Data or Raster Imagery

We are experts in offline limited availability mapping

Vector Tile Basemaps and OverViews

Area of Interest of existing Mbtiles and GeoPackages

Downloading of OGC Mapping Services for offline use (WMS, WFS, WCS, WMTS, TMS/XYZ)

Downloading of ESRI ArcGIS Mapping Services (Feature, Image, Map)



Other Supported Formats

Other Formats Supported:

  1. BSB Nautical Chart Format (KAP)
  2. Tagged Image Format (GeoTiff)
  3. JPG2000  JP2, JPK
  4. KML SuperOverlay and KMZ
  5. OziExplorer .map
  6. OziExplorer .OZFx2 and 3
  7. Meta Raster Format (MRF)
  8. OZI
  9. Geospatial PDF (GeoPDF)
  10. Rasterlite
  11. ESRI TilePackage (TPK)
  12. ZMap Plus
  13. Garmin JNX Format
  14. RMaps SQLite
  15. MapTech Topo Maps and Aerial Navigation Chart
  16. NITF RPF
  17. ECW
  18. Zoomify Format
  19. Enterprise Database Raster formats (Oracle Spatial, MySQL Spatial, POSTGIS, SQL Server Spatial, DB2, etc)
  20. Different tiling schemas

MBTILES SQLite

MBTILES is probably the best format with vector tiles and raster tiles.  GeoPackage is good with it’s Vector Features (similar to WKB geom column) and flexible projections for raster tiles.

Data Products

We have many data products staged and ready to go.

We can also cut an area of interest (clip) the data and also reduce the number of zoom levels as needed to keep file size down.
